Item Number :2493760

UPC Code : 785988031146

UNSPSC Code : 39111544

Brand :Hubbell Lighting

INTENDED USAGE

• Perimeter lighting for safety and security. Use on factories warehouses self-storage commercial buildings etc.


CONSTRUCTION

• Borosilicate glass refractor softens lamp image and provides uniform distribution
• Cast aluminum frame holds lens and seals to housing gasket with two stainless steel screws.
• Door assembly hinges down on large units
• Cast aluminum housing with three 1/2" conduit entries (on top and sides) for button photo control or surface conduit
• All units have dark bronze powder paint finish


Operating Temperature:

• -30 degree C to 40 degree C


LED:

Mid Power - Large Housing

225 LEDs 10151 lumens 4000K 80 CRI

• Mid power LEDs offer lower glare better uniformity higher efficacies (up to 105 LPW) and lower thermals for longer lasting electronic components


Electrical:

• Driver RoHS and IP66
• Single 120V-277V 50/60Hz driver
• 225L: 1 X 97W 125mA 105 LPW


Listings:

• Listed to UL1598 for use in wet locations
