Product Details
＋
Built upon the formidable foundations of 23 SALTIGA, the new 24 CERTATE SW features AIRDRIVE DESIGN decreasing winding resistance & reducing the weight of the front unit. The new ZAION AIRDRIVE ROTOR is what sets it apart from SALTIGA, but it’s what it shares with SALTIGA that makes this reel so suited to Australia’s harsh conditions.
It all begins with a solid one-piece aluminium monocoque (MQ) body, housing an oversize G1 Duralumin drive gear for increased winding power, strength & gear durability. The MQ body eliminates flex & twisting and improves weather sealing thanks to the one-piece construction with no seams or screws to hold a side plate on.
24 CERTATE SW is now available from 4000-6000 sizes in both H & XH ratios. The addition of the 4000 size now puts it firmly in the limelight for a workhorse snapper reel, barramundi or other heavy-duty fishing which doesn’t require high line-capacity of heavy PE line
Daiwa Technology
MONOCOQUE BODY
Strong and durable technology, monocoque body. Conventional spinning reels generally support both ends of the drive gear with the body and body cover, and secure them with several screws. In order to further improve precision and rigidity, the monocoque body eliminates the body cover and secures the gear by screwing a high-precision plate directly into the body. This improves the gear support precision, rigidity, and airtightness. Furthermore, by utilizing the space previously taken up by the screw, we have succeeded in expanding the size of the drive gear to its maximum. The monocoque body means MONO (one) - COQUE (shell). The completely new shape, which symbolizes the strength of a single shell, breaks the conventional wisdom of reel structure.
It uses a full metal (aluminum) monocoque body. The maximum diameter Tough Digigear is enclosed in a highly rigid, lightweight, compact housing.
TOUGH DIGIGEAR
To survive in harsh environments, a reel needs a strong heart. "Tough Digigear" keeps the rotation smooth for longer.
The G1 duralumin (ultra-high strength aluminum) used in 24 CERTATE SW is both strong and lightweight.
AIRDRIVE DESIGN
Air Drive Design is a next-generation spinning reel design concept that pursues the angler's desire to operate the lure as they wish. Air Drive Design is composed of up to four technologies. The prerequisite is the installation of an Air Drive Rotor that produces light winding and high-response rotation, a lightweight and trouble-free Air Drive Bail, a thin-walled Air Drive Spool that has been designed to reduce weight by removing unnecessary material to the limit, and an Air Drive Shaft that supports the main shaft with a high-precision collar and has a non-contact structure with the pinion gear, allowing for light winding with extremely little rotation noise even under high load. The synergistic effect of these and the improvement of the weight balance of the reel achieve a high level of operability.
*The 24 CERTATE SW4000/5000/6000 are equipped with three features: AIRDRIVE ROTOR, AIRDRIVE BAIL, and AIRDRIVE SHAFT.
AIR DRIVE ROTOR
Using our unique theory, we have derived a new shape that looks as if it was cut out of a sphere, and by thoroughly removing unnecessary material from it, we have achieved a significant weight reduction while maintaining rigidity. This has dramatically improved the lightness of the reel, which leads to improved operability and sensitivity.
The new ZIAON AIRDRIVE ROTOR was developed for 24 CERTATE SW. Its low inertia and strength-oriented settings enable sharp and technical lure control with high response, giving anglers an overwhelming advantage.
AIR DRIVE BAIL
The Air Bail has adopted a hollow pipe structure that provides rigidity and light weight, but in order to achieve further weight reduction, the diameter has been made smaller while maintaining the necessary strength. The bail angle is set to the optimum angle to allow the line to transition more smoothly from the veil to the line roller. This has made it even lighter and less troublesome.
24 CERTATE SW uses the optimal bail diameter for each size. The 6000 size has a Φ3.0mm diameter that prioritizes strength, while the 4000/5000 sizes have a Φ2.4mm diameter that prioritizes operability.
AIR DRIVE SHAFT
The system uses a non-contact structure between the main shaft and pinion, a linear shaft that eliminates friction, and supports both ends of the pinion with bottom brackets, maximizing the power input to generate torque. Furthermore, the main shaft is supported by a high-precision collar, which reduces rotational noise to the maximum.
MAGSEALED
DAIWA's unique waterproof structure creates a wall of magnetic mag oil in the gap between the body and rotor, blocking out seawater, dust, and other elements.
This technology is installed in two places in the 24 CERTATE SW4000/5000/6000: the pinion and the line roller. It further improves waterproofness, durability, and rotation performance, achieving a high level of waterproofness.
ATD (TOUGH)
The ATD operates smoothly and keeps working smoothly in response to the pull of the fish. The ATD Tough uses carbon washers to achieve high durability. It pursues smooth start and tracking, allowing you to concentrate on the fight without worrying about the drag setting.
4000: 3 carbon washers, 5000/6000: 5 carbon washers.
LC-ABS (Long Cast ABS)
While keeping the idea of reducing contact resistance of ABS II, the contact point has been moved forward to achieve smoother line release. The effect of the ring part moving forward makes it difficult for the line to get on the ring, which has resulted in an approximately 5% increase in distance and trouble-free performance over the conventional ABS II. This is the next generation ABS spool that achieves LC (= LONG CAST).
Product Details
■ Stopperless body
The body structure has been simplified by removing the stopper. The decision to remove the stopper, which is a route through which water and foreign objects can enter, not only improves waterproof performance but also minimizes the risk of sudden trouble in harsh environments or when dealing with large fish, which are required for 24 CERTATE 4000/5000/6000.
■ Manual return
In order to completely prevent the bail from flipping back when casting and to improve durability, a manual return mechanism is used that prevents the bail from flipping back when the handle is turned.
■ Power light knob (compatible with S size knob)
Uses a Power Light Knob L (replaceable for S size) made of EVA, which is easy to grip and non-slip.
■24CERTATE SW ball bearings installed in places
※10BB installed
・Pinion 2BB (CRBB)
・Drive gear 2BB (CRBB)
・Line roller 2BB (CRBB)
・Handle knob 2BB (CRBB)
・Main shaft 1BB (CRBB)
・Oscillating gear 1BB (CRBB)
(※1BB can be added to the spool and spool metal)
※10BB installed
・Pinion 2BB (CRBB)
・Drive gear 2BB (CRBB)
・Line roller 2BB (CRBB)
・Handle knob 2BB (CRBB)
・Main shaft 1BB (CRBB)
・Oscillating gear 1BB (CRBB)
(※1BB can be added to the spool and spool metal)
Accessories
・Spool position adjustment washer
・Handle knob removal screwdriver
Product Videos
Specification
| MODEL | Ball Bearing | Drag | Gear | Line Capacity | Weight |
| 4000-H | 10CRBB; 1RB | 12kg | 5.7 | PE 2/300m | 335g |
| 4000-XH | 10CRBB; 1RB | 12kg | 6.2 | PE 2/300m | 335g |
| 5000-H | 10CRBB; 1RB | 15kg | 5.7 | PE 2.5/300m | 345g |
| 5000-XH | 10CRBB; 1RB | 15kg | 6.2 | PE 2.5/300m | 345g |
| 6000-H | 10CRBB; 1RB | 15kg | 5.7 | PE 3/300m | 375g |
| 6000-XH | 10CRBB; 1RB | 15kg | 6.2 | PE 3/300m | 375g |
Line Up
24 CERTATE SW (G) 5000-H
24 CERTATE SW (G) 5000-XH
24 CERTATE SW (G) 6000-H
24 CERTATE SW (G) 6000-XH
